Key facts
- Brand
- Yamaha
- Model
- MSR400
- Category
- Home Speakers
- Industry
- Computers
- Documents
- 2
- Languages
- EN
- Last added
- 2012-05-03
Start here
YAMAHA rx-v467 POWERED SPEAKER MSR400 owner's Manual
This manual introduces the Yamaha RX-V467 AV receiver, describing its built‑in 5‑channel amplifier, speaker‑connection options, and supported sound‑field programs. It lists supplied accessories, explains front‑panel controls, remote‑control functions, and HDMI features.
Detailed sections cover speaker wiring, sub‑woofer setup, HDMI and Bluetooth connections, YPAO automatic speaker calibration, and extensive setup menus. An appendix provides technical specifications, troubleshooting tips, and a glossary of terms.
Yamaha MSR400 specifications
| Maximum Output Level | 121 dB (1 m on Axis) |
|---|---|
| Directional Angle | 90° (H) / 40° (V) |
| Dimensions (W × H × D) | 406 × 652 × 351 mm |
| Weight | 23 kg |
| Input Sensitivity (MIC/LINE) | ‑36 dB / +4 dB |
| Input Impedance | 10 kΩ |
All Yamaha MSR400 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What type of input/output connectors are on the MSR400?
The speaker provides XLR‑3‑31 (female), XLR‑3‑32 (male) and balanced phone‑jack connectors, all wired in parallel.
What safety precautions are required for the power cord?
Use only the included power cord, keep it away from heat sources, and do not let it become frayed, pinched, or walked on.
How can I automatically set speaker parameters with YPAO?
Connect the supplied YPAO microphone to the YPAO MIC jack, then run the YPAO setup to measure and adjust speaker acoustic parameters automatically.
What is the correct way to connect a subwoofer?
Plug the subwoofer’s built‑in amplifier cable into the SUBWOOFER jack on the rear panel.
