Start here
Sony WLL-CA50 / WLL-RX50 Wireless Camcorder System Installation Manual
The Sony wireless camcorder system (model WLL-CA50 transmitter and WLL-RX50 receiver) enables real‑time MPEG‑2 video and MPEG‑1 audio transmission over a 2.4 GHz COFDM link, allowing flexible, cable‑free operation of Sony camcorder units in news and sports broadcasting.
Key features include secure encryption, split‑receiver diversity, time‑interleaved error correction, up to seven selectable RF channels with 2‑MHz steps, low power consumption (9 W TX), and a user‑friendly LCD menu that displays status and alarms. The system complies with standard V‑type camcorder connectors and includes interchangeable N‑type antenna options. This manual is written in Chinese.
SONY WLL-CA50 specifications
| Transmitter power supply | 12 V DC |
|---|---|
| Receiver power supply | AC 100‑240 V 50/60 Hz |
| Operating temperature range | 0 °C to +40 °C |
| Dimensions (W×H×D) | 462 × 52 × 439 mm |
| Transmitter frequency range | 2406‑2470 MHz |
| Receiver frequency range | 2406‑2478 MHz |
| Modulation | 16 QAM‑COFDM, QPSK‑COFDM |
| Channel bandwidth | 8 MHz |
| Transmitter antenna gain | 9.0 dBi |
| Receiver antenna gain | 4.0 dBi |
Source: Sony WLL-CA50 / WLL-RX50 Wireless Camcorder System Installation Manual
All SONY WLL-CA50 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
What frequency range does the WLL-CA50 transmitter operate in?
The transmitter operates between 2406 MHz and 2470 MHz.
From: Sony WLL-CA50 / WLL-RX50 Wireless Camcorder System Installation Manual
How many RF channels can be selected on the system?
Up to seven channels can be selected, with 2‑MHz steps and optional 1‑MHz fine tuning.
From: Sony WLL-CA50 / WLL-RX50 Wireless Camcorder System Installation Manual
