DELL XPS 630i Manuals

ManualLib has 11 documents for the DELL XPS 630i (Desktops): 3 service manuals, 7 user manuals, 1 quick start guide. Every file can be read online or downloaded as a PDF for free.

Service Manual 3User Manual 7Quick Start Guide 1

Key facts

Brand
DELL
Model
XPS 630i
Category
Desktops
Industry
Computers
Documents
11
Languages
IT · FR · ES · EN · PT · ZH
Last added
2023-11-24

Start here

Dell XPS 630i Desktop Computer Setup Guide

Dell XPS 630i Desktop Computer Setup Guide

Quick Start Guide 2 pages · 1.1 MB · EN

This Dell setup guide covers initial setup of the Dell XPS 630i desktop computer. It explains connecting the monitor using either the white DVI cable or the blue VGA cable, but not both.

It also covers connecting the keyboard and mouse, network and modem cables, power cables, and pressing the power buttons. Rear panel connector locations and an optional wireless network diagram are included.

Read online

DELL XPS 630i specifications

IEEE 1394 connector1
Microphone connector1
Headphone connector1
USB 2.0 connectors2

Source: Dell XPS 630i Desktop Computer Setup Guide

All DELL XPS 630i documents by type

Service Manual 3

Disassembly, diagnostics and part numbers, for repair.

Quick Start Guide 1

The shortest path to a working setup, usually only a few pages.

Questions answered in these manuals

What is the procedure for shutting down the computer to prevent data loss?

Save and close all open files and exit all running programs before turning off the computer.

From: Dell XPS 630i Service Manual

How long must the power button be held to turn off the computer if it does not shut down automatically?

Hold the power button for 4 seconds if the computer and connected devices do not turn off automatically.

From: Dell XPS 630i Service Manual

What tools are recommended for servicing the Dell XPS 630i?

A small Phillips screwdriver and a support for the Flash BIOS update program.

From: Dell XPS 630i Technical Guide

How should the computer be shut down before service?

Save and close all open files and programs, then shut down through the operating system; if needed, hold the power button for about 4 seconds.

From: Dell XPS 630i Technical Guide

Which cables should I use to connect the monitor?

Use either the white DVI cable or the blue VGA cable, but do not use both cables.

From: Dell XPS 630i Desktop Computer Setup Guide

Is the network cable included?

No, the network cable is not included.

From: Dell XPS 630i Desktop Computer Setup Guide
