Key facts
- Brand
- ASUS
- Model
- P5L-VM
- Category
- Motherboard
- Industry
- Computers
- Documents
- 2
- Languages
- JA · ZH
- Last added
- 2011-09-20
Start here
ASUS P5L-VM 1394 Motherboard User Manual
This manual provides detailed instructions for installing and configuring the ASUS P5L-VM 1394 motherboard. It includes safety guidelines, hardware layout, jumper settings, BIOS configuration, and software support.
The document also explains advanced features such as Intel Hyper‑Threading, Power Management options, and how to update the BIOS using ASUS EZ Flash 2. This manual is written in Japanese.
ASUS P5L-VM specifications
| Memory Type | DDR2 |
|---|---|
| PCI Express Slots | x16 and x1 |
| PCI Express Slots | x1 |
All ASUS P5L-VM documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do I enable Intel Hyper‑Threading on this motherboard?
Install a Hyper‑Threading‑capable Intel Pentium 4 CPU, enter the BIOS Setup, go to the Advanced menu and set the Hyper‑Threading Technology option to Enabled, then save and exit.
What is the recommended method to update the BIOS?
Use the ASUS EZ Flash 2 utility from within the BIOS to load the new BIOS file and flash the chip.
What type of CPU does the P5L-VM 1394 support?
It supports LGA775 processors such as Intel Core2 Extreme/Duo, Pentium D, Pentium 4 and Celeron D.
How many USB 2.0 ports are available on the motherboard?
The board provides up to eight USB 2.0 ports.
