The MC100LVEL29 is a dual master-slave flip flop.
This document provides technical specifications for the Motorola MC100LVEL29 and MC100EL29, which are dual master-slave D flip-flops with fully differential Data and Clock inputs. The devices feature asynchronous Set and Reset inputs and operate at high frequencies up to 14 GHz (MC100LVEL29) or 11 GHz (MC100EL29).
| Maximum Toggle Frequency (MC100LVEL29) | 14 GHz |
|---|---|
| Maximum Toggle Frequency (MC100EL29) | 11 GHz |
| Propagation Delay (Typical) | 580 ps |
| Package Type | 20-lead SOIC |
It is a dual master-slave flip flop with fully differential Data and Clock inputs as well as outputs.
Both flip flops feature asynchronous, overriding Set and Reset inputs that cannot both be HIGH simultaneously.
