The 74LCX00 is a low voltage quad 2-input NAND gate with 5V tolerant inputs. It is fabricated with advanced CMOS technology to achieve high speed operation while maintaining low power dissipation.
The 74LCX00 is a low voltage quad 2-input NAND gate fabricated with advanced CMOS technology. It features 5V tolerant inputs, allowing the interface of 5V systems to 3V systems, while maintaining high speed operation and low power dissipation. The device includes patented noise/EMI reduction circuitry and offers latch-up performance exceeding 500 mA.
| Supply Voltage (Vcc) | 2.3V-3.6V |
|---|---|
| Propagation Delay (tp) | 5.2 ns max |
| Output Drive Current | +24 mA |
| Latch-up Performance | > 500 mA |
| ESD Performance (Human Body Model) | > 2000V |
| Operating Temperature Range | -40 to +85 °C |
The supply voltage specifications are provided for 2.3V to 3.6V.
Yes, the inputs tolerate voltages up to 7V, allowing the interface of 5V systems to 3V systems.
The maximum propagation delay is 5.2 ns when Vcc is 3.3V.
