The LCX08 is a low voltage quad 2-input AND gate with inputs that can tolerate voltages up to 7V, allowing the interface of 5V systems to 3V systems. The 74LVX08 is fabricated with advanced CMOS technology to achieve high speed operation while maintaining CMOS low power dissipation.
The document describes the 74LCX08 integrated circuit, which contains four 2-input AND gates. It is fabricated using advanced CMOS technology to achieve high speed while maintaining low power dissipation. A key feature is its ability to interface 5V systems with 3V systems due to inputs that tolerate voltages up to 7V.
| Operating Temperature Range | -40°C to +85°C |
|---|---|
| Output Drive Current | +/- 24 mA |
Yes, the inputs are designed to tolerate voltages up to 7V.
The LCX08 contains four 2-input AND gates.
