This PDF document introduces a new generation of trench MOSFETs from Zetex, which combines the benefits of low on-resistance with fast switching speed. This makes them ideal for high efficiency, low voltage, power management applications.
The document describes the Zetex ZXMH C3A01T8, a new generation of trench MOSFETs designed to combine low on-resistance with fast switching speed. These devices are ideal for high efficiency, low voltage power management applications, such as single phase DC fan motor drives.
The datasheet provides comprehensive specifications for both N-Channel and P-Channel variants, including absolute maximum ratings, electrical characteristics, typical performance curves, and package dimensions. It specifies a 30V drain-source voltage rating and currents up to 3.4A continuous for the N-channel device.
| Operating temperature range | -55 to +150 °C |
|---|---|
| Package type | SM-8 surface mount package |
The device can operate and be stored in a temperature range from -55 to +150 °C.
The N-channel version dissipates up to 1.3 W, and the P-channel version dissipates up to 1.7 W.
