The ASI MLN1037F is a NPN silicon RF power transistor from Advanced Semiconductor, Inc. It features the Omnigold™ metallization system, and is rated for 10 A current, 60 V and 35 V voltage, and a maximum power dissipation of 140 W.
The ASI MLN1037F is an NPN silicon RF power transistor designed with the Omnigold™ Metalization System. It features a TO-252FL package style and operates within a junction temperature range of -65 °C to +200 °C.
Key specifications include a maximum collector current (Ic) of 10A, a collector-emitter voltage (Vce) rating of 35V, and a power dissipation of 140W at 25°C. The device supports operating temperatures from -65 °C to +150 °C.
| Collector-Emitter Voltage (Vce) | 35 V |
|---|---|
| Power Dissipation (Poiss) | 140 W @ Tc = 25 °C |
| Operating Temperature Range (Tj) | -65 °C to +200 °C |
| Storage Temperature Range (Tstg) | -65 °C to +150 °C |
| Thermal Resistance (Rthjc) | 5.5 °C/W |
| Package Style | .250 2L FLG |
It can dissipate up to 140 W when the case temperature is 25 °C.
The device operates from -65 °C to +200 °C and stores from -65 °C to +150 °C.
