ILC6363CIR-50 / ILC6363CIR-ADJ is a DC-DC converter with adjustable output voltage, supporting 500mA output current, input voltage range of 3.6V-12V, output voltage range of 0.8V-6V, and peak efficiency up to 90%.
The ILC6363 is a step-up/step-down DC-DC converter capable of supplying up to 500mA output current at a fixed or user-selectable output voltage. It is optimized for applications using single Lithium-Ion batteries where the input voltage range spans above and below the regulated output voltage. The device features an internal synchronous rectifier, eliminating the need for an external diode, and operates at a frequency of 300kHz.
| Maximum Output Current | 500mA |
|---|---|
| Peak Efficiency | > 90% |
| Oscillator Frequency | 300kHz |
| Package Type | MSOP-8 |
| Operating Ambient Temperature | -40 to 85 °C |
| Output Voltage (Fixed) | 5.0V |
| Maximum Adjustable Output Voltage | 6V |
No, the device does not require an external diode as it features synchronous rectification.
The low battery detector includes a 100ms transient rejection delay.
Yes, it can perform a limited buck operation in PFM mode when the input voltage is up to 0.8V higher than the output voltage.
