This document is a customer acceptance specification sheet and datasheet for the Hitachi TX09D50VM1CCA, an active matrix transmissive color TFT LCD module. The device features a resolution of 240 x 320 dots and includes a built-in touch panel with resistive technology.
| Resolution | 240 x 320 dots |
|---|---|
| Display Type | Active Matrix Transmissive Color TFT LCD |
| Number of Colors | 262,144 colors |
| Effective Display Area | 53.64(W)mm x 71.52(H)mm |
| Power Supply Voltage (Typ) | 3.3 V |
| Touch Panel Resistance (xR - xL) | 200 - 650 ohm |
The absolute maximum rating for the power supply for logic (VDD) is 4.0 V.
The module can operate in an ambient temperature range from -10°C to 50°C.
The maximum forward current (IF) for each LED part is 25 mA.
