RZF030P01 is a 1.5V drive Pch MOSFET produced by ROHM. It features low on-resistance, high power package, low voltage drive, and is suitable for switching applications.
The RZFO30P01 is a P‑channel MOSFET designed for low‑voltage (1.5 V) drive applications. It features low on‑resistance, a high‑power package, and built‑in ESD protection diodes.
The datasheet provides electrical characteristics, absolute maximum ratings, thermal resistance, and typical application circuits. Packaging details and measurement methods are also included.
| Drain‑source voltage (Vdss) | -12 V |
|---|---|
| Gate‑source voltage (Vgss) | +10 V |
| Continuous drain current (Id) | +3 A |
| Pulsed drain current (Id,pulse) | +12 A |
| Total power dissipation (Pd) | 0.8 W |
| Maximum channel temperature (Tj) | 150 °C |
| Thermal resistance (RθJA) | 156 °C/W |
The device can handle a continuous drain current of +3 A.
It is a low‑voltage drive MOSFET that operates with a 1.5 V gate drive.
The package is identified by Type Code TL with a basic ordering unit of 3000 pieces.
