This document describes the features and characteristics of the PST 1,3/ 4-LV-5,0 product produced by PHOENIX CONTACT GmbH & Co. KG. The product is a header connector with 10 positions, rated current of 14A, rated voltage of 250V, pitch of 5mm, black color, and can be assembled through soldering.
The PST 1,3/4-LV-5,0 is a 4‑position, 5 mm pitch terminal block designed for soldered assembly. It is rated for a nominal current of 14 A and a nominal voltage of 250 V, with a compact length of 10.8 mm and a weight of 0.00148 kg per piece.
The product complies with RoHS and WEEE regulations (since 07/02/2007) and holds UL and CUL certifications. Ordering information, dimensions, and detailed drawings are provided in the sheet, and the manufacturer’s contact details are listed for further support.
| Nominal current | 14 A |
|---|---|
| Nominal voltage | 250 V |
| Pitch | 5 mm |
| Number of positions | 4 |
| Length | 10.8 mm |
| Dimension a | 15 mm |
| Pin dimensions | 1.3 mm |
| Weight per piece | 0.00148 kg |
| EAN | 4017918995089 |
| Maximum load current | 13.5 A (depends on plug) |
The terminal block is rated for a nominal current of 14 A.
It has four positions.
Yes, it has been RoHS‑compliant since 07/02/2007.
