UT 6 BU is a universal terminal block with screw connection from TE Connectivity, with a cross section of 0.2-6 mm², AWG 24-8, a width of 8.2 mm and a colour of blue.
The UT 6 BU is a universal terminal block with screw connection, designed for conductor cross sections from 0.2 mm to 6 mm. It is supplied in a blue housing and offers a nominal current of 57 A and a nominal voltage of 1000 V.
Technical data include a stripping length of 10 mm, an M4 screw thread, and a minimum tightening torque of 1.5 Nm. The product is rated for a surge voltage of 8 kV and complies with IEC/DIN VDE standards.
| Stripping length | 10 mm |
|---|---|
| Screw thread | M4 |
| Minimum tightening torque | 1.5 Nm |
It uses a screw connection.
The minimum tightening torque is 1.5 Nm.
