The LAU300 is a titanium load‑cell sensor from FUTEK Advanced Sensor Technology, Inc., designed for precise force measurement. It features a rated output of 2 mV/V and a safe overload capacity of 180 % of rated output.
The sheet lists detailed electrical specs, temperature compensation data, and mechanical dimensions, along with optional Microtech ER‑7S mating connector cable assemblies and calibration recommendations for belt‑type installations.
| Rated Output | 2 mV/V nominal |
|---|---|
| Safe Overload | 180 % of rated output |
| Zero Balance | 43 % of rated output |
| Bridge Resistance | 350 mΩ nominal |
| Non‑repeatability | 0.5 % of rated output |
| Temperature Shift Zero | 40.02 % of R.O./°F (0.04 % of R.O./°C) |
| Temperature Shift Span | 0.02 % of load/°F (0.04 % of load/°C) |
| Compensated Temperature Range | 60 °F to 160 °F (16 °C to 77 °C) |
| Operating Temperature Range | 0 °F to 200 °F (‑18 °C to 73 °C) |
| Sensing Element Material | Titanium |
| Frame Material | Aluminum |
| Connector Type | Microtech ER‑7S |
The LAU300 provides a nominal rated output of 2 mV/V.
It can tolerate up to 180 % of its rated output without damage.
An optional Microtech EP‑7S mating connector with a 10‑ft (2 m) 7‑conductor braided shielded Teflon cable is available.
Submit a minimum 2‑ft belt to be calibrated together with the sensor for best results.
