NC7SP05 is a single inverter with open drain output from Fairchild's Ultra Low Power (ULP) series of TinyLogic®. Ideal for applications where battery life is critical, this product is designed for ultra low power consumption within the VCC operating range of 0.9V to 3.6V VCC. The internal circuit is composed of a minimum of inverter stages, including the output buffer, to enable ultra low static and dynamic power. The NC7SP05, for lower drive requirements, is uniquely designed for optimized power and speed, and is fabricated with an advanced CMOS technology to achieve best in class speed operation while maintaining extremely low CMOS power dissipation.
The NC7SP05 is a single inverter from Fairchild’s TinyLogic ultra‑low‑power (ULP) series. It provides an open‑drain output that operates from 0.9 V to 3.6 V supply voltage, making it suitable for battery‑powered applications that require minimal static and dynamic power consumption.
The datasheet lists absolute maximum ratings, DC and AC electrical characteristics, propagation delays, and package information for the 5‑lead SC70 and 6‑lead MicroPak versions. Physical dimensions, tape‑and‑reel handling specifications, and a life‑support policy are also included.
| Supply Voltage (Vcc) range | 0.9 V to 3.6 V |
|---|---|
| Input Diode Current (Iin) max | 50 mA |
| Output Source/Sink Current max | 50 mA |
| Typical Propagation Delay at 3.0 V | 0.90 ns |
The device operates from 0.9 V to 3.6 V supply voltage.
The static drive current is 42.6 mA at 3.0 V Voc.
The device can be stored from –65 °C to +150 °C.
