This manual is about the usage of a color scanner produced by Tsinghua Unisplendour Corporation Limited. It includes instructions on installation, configuration, usage, and maintenance of the scanner.
This manual covers the complete setup of the Uniscan C600 scanner, including unpacking, connecting the power adapter and USB cable, installing drivers, and testing the device. Detailed safety precautions are provided to prevent damage and ensure safe operation.
It also explains the functions of the scanner’s five hardware buttons, the Uniscan TWAIN interface, and the accompanying software tools such as Presto! ImageFolio and Uniscan Manager. An appendix lists the technical specifications of the scanner. This manual is written in Chinese.
| Physical dimensions (W×D×H) | 435×265×75 mm |
|---|---|
| Weight | 2.5 kg |
| Operating temperature | 10 °C to 40 °C |
| Maximum scan area (reflective) | 216 mm×297 mm (8.5"×11.69") |
| Maximum scan area (film) | 35 mm film, 35 mm slide, 120/220 film up to 60×90 mm |
| Color scan mode | Input 48‑Bit, Output 24/48‑Bit |
| Grayscale scan mode | Input 16‑Bit, Output 8/16‑Bit |
| Black‑white scan mode | 1‑Bit |
| Optical resolution | 2400 × 4800 dpi |
| Maximum software resolution | 24000 dpi |
| Interface | USB 2.0 |
| Power adapter output | DC 15 V, 1.0 A |
| Power consumption (operating) | 15 W |
| Power consumption (standby) | 5 W |
