This manual introduces the use of Uniscan scanner, including installation, use, maintenance and scanning tips.
This manual explains how to safely install and configure the Uniscan B600 scanner, including connecting the supplied USB cable, installing drivers from the provided CD, and performing initial test scans. Safety precautions such as avoiding moisture, using the automatic protection lock, and disconnecting power when not in use are also covered.
The guide details the scanner’s functions, including the five hardware buttons, the Uniscan Manager software, OCR and copy features, and how to export scanned files to applications like Excel. An appendix lists the technical specifications of the device. This manual is written in Chinese.
| Dimensions (W×D×H) | 265 mm × 435 mm × 6 mm |
|---|---|
| Weight | 2.5 kg |
| Operating Temperature | 10 °C to 40 °C |
| Maximum Scan Area (Reflective) | 216 mm × 297 mm (8.5 in × 11.69 in) |
| Color Input Bit Depth | 48‑Bit |
| Grayscale Input Bit Depth | 16‑Bit |
| Black‑White Bit Depth | 1‑Bit |
| Optical Resolution | 2400 dpi (software max 24000 dpi) |
| Interface | USB 2.0 |
| Lamp Type | Cold cathode |
| Power Adapter Output | DC 15 V, 1.0 A |
| Maximum Power Consumption | 15 W |
Insert the supplied driver CD into the computer; the system will automatically open the installation interface and guide you through the driver setup.
The scanner provides an optical resolution of 2400 dpi, while the software can process up to 24000 dpi.
When saving, choose the file type "html" (htm); the resulting file can be opened directly in Excel.
Make sure the driver and Uniscan Manager software are installed; then select "Uniscan XXX" from the TWAIN source dialog and click "Select".
