This is a three-phase inverter module suitable for photovoltaic power generation systems and fuel cell systems
This application note provides an overview of Mitsubishi Electric's PV‑IPM intelligent power modules, including their features, product line‑up, and terminology. It explains the numbering system, internal structure, and recommended installation practices.
Safety guidance covers proper storage, handling of static electricity, mounting torque, and thermal design considerations. The document also includes calculation methods for power loss and junction temperature, and a notice on safe design practices.
