This document describes the features and characteristics of the Transistor-Array series products, as well as their use in various applications. The product range offers a wide range of options to help reduce the size and weight of application sets. It is widely used in vending machines, sequencers, measurement instruments, elevators, air-conditioners, fan heaters, washing machines, refrigerators, hot water dispensers, and more. The document also provides detailed information on the product's function reference, circuit/pin connection, thermal derating factor characteristics, and application examples.
The Transistor-Array series from Mitsubishi Electric provides compact, surface‑mount semiconductor arrays that convert a small input current into a higher drive current. The series covers a wide range of applications such as arcade games, vending machines, elevators, air‑conditioners, printers and many other equipment.
The document lists the part numbers (e.g., M54523P, M63820FP), their electrical specifications such as output withstand voltage, sink current, and the available package types (DIP, SOP, SSOP). Package dimensions and pin‑out diagrams are also included for each variant.
