This leaflet introduces the DIPPSC series of Intelligent Power Modules (IPM) developed by Mitsubishi Electric. It highlights the series' high voltage capability (600 V and 1200 V), a wide current range (3 A‑75 A), and design features such as lead‑free terminals, improved heat‑dissipation structures, and built‑in temperature monitoring.
The document also lists typical applications—including residential appliances (air‑conditioners, refrigerators, washing machines) and small‑power industrial equipment (inverters, servo systems)—and presents model numbers with their corresponding current and voltage ratings. Additional sections describe power‑factor improvement options (full‑SW and partial‑SW circuits) and compliance with RoHS standards. This manual is written in Chinese.
| Current rating (600 V) | 3 A‑75 A |
|---|---|
| Current rating (1200 V) | 5 A‑35 A |
| Voltage rating | 600 V and 1200 V |
| RoHS compliance | Lead‑free external terminals |
| Temperature monitoring | Built‑in temperature output function |
| Over‑heat protection | Included |
The series offers 3 A‑75 A ratings for 600 V devices and 5 A‑35 A ratings for 1200 V devices.
Yes, the external wiring terminals are lead‑free and meet RoHS requirements.
Yes, the package includes a temperature output function for monitoring.
They are used in white‑goods such as air‑conditioners, refrigerators, washing machines, as well as in small‑power industrial equipment like inverters and servo systems.
