G3VM-41GR6 is a MOSFET produced by OMRON. It features low on-resistance, low gate capacitance, and low leakage current. It is suitable for LED driver circuits.
The G3VM-41GR6 is a MOS FET relay designed for low capacitance (1 pF) and low off‑state leakage (1 nA). It supports a maximum load voltage of 40 V and includes LED indicators with a forward current of 530 mA.
The document lists electrical characteristics such as continuous load current up to 120 mA (peak AC/DC), recommended operating temperature of 25 °C, and provides terminal configuration and internal wiring diagrams for proper installation. This manual is written in Chinese.
| Maximum load voltage | 40 V |
|---|---|
| Output terminal capacitance | 1 pF |
| Off‑state leakage current | 1.0 nA |
| LED forward current | 530 mA |
| Recommended operating temperature | 25 °C |
The relay is rated for a maximum load voltage of 40 V.
The off‑state leakage current is specified as 1.0 nA.
