This document describes the features and characteristics of a MOS FET product, including its appearance, electrical parameters, and operating temperature range.
The G3VM-41LR11 is an ultra‑small SSOP‑packaged MOS FET relay offering a low input capacitance of 5 pF and a standard on‑resistance of 79 mΩ. It is designed for applications requiring minimal signal distortion and compact board space.
Key electrical characteristics include a maximum load voltage of 40 V, LED forward voltage between 1.15 V and 1.45 V, LED forward current of 20 mA for actuation, and a continuous load current rating of 140 mA. Recommended operating temperature is 25 °C, and the device provides typical actuation and release times around 2 ms. This manual is written in Chinese.
| Package | SSOP (world's smallest) |
|---|---|
| Input capacitance (CXR) | 5 pF |
| On‑resistance (Ron) | 79 mΩ (standard) |
| Maximum load voltage | 40 V |
| Recommended operating temperature | 25 °C |
The relay can handle a maximum load voltage of 40 V.
The recommended operating temperature is 25 °C.
