G3VM-41GR8 is a 1A, 40V N-channel MOSFET from OMRON, which integrates a driver circuit and is packaged in SOP4. The operating temperature range is -55℃～+125℃.
The Omron G3VM-41GR8 is a MOS FET relay that offers low on‑resistance comparable to mechanical relays, suitable for switching up to 1 A in SOP packages.
The manual lists key electrical parameters such as 1500 V rms isolation, 0.19 Ω on‑resistance, LED drive requirements, and provides recommended operating conditions and wiring diagrams. This manual is written in Chinese.
| Continuous load current | 1 A |
|---|---|
| Maximum isolation voltage (input‑output) | 1500 V rms |
| On‑state resistance | 0.19 Ω |
| LED forward current | 30 mA |
The relay can continuously carry a load current of 1 A.
The isolation voltage between input and output is rated at 1500 V rms.
Drive the LED with a forward current of 30 mA.
