ARCH AQF120O-180W AC-DC Switching Power Supply is a 180W switching power supply with high efficiency, wide input voltage, low noise, and fanless cooling.
This document provides technical specifications for the ARCH AQF1200 Series of open frame AC-DC switching power supplies. The series offers various output voltages ranging from 5V to 48V with maximum wattages of 120W or 180W depending on the fan configuration. Key features include a universal input voltage range of 90-264 VAC, high efficiency up to 93%, and a power factor correction (P.F.C.) function greater than 0.95.
| Max Output Wattage (18CFM FAN) | 180 W |
|---|---|
| Max Output Wattage (30CFM FAN) | 150 W |
| Input Voltage | 90-264 VAC |
| Power Factor | >0.95 |
| Operating Temperature | -25°C...+70°C |
| Efficiency (typ.) | Up to 93% |
| Dimensions (Standard) | 5.0 x 3.0 x 1.16 Inches |
The maximum output wattage is 120 W when operating with free air convection.
The product comes with a three-year warranty.
The input inrush current is less than 60 A max. at 230 VAC.
