Sony SNC-CS20 Network Gun Camera Manual
The SNC‑CS20 is a high‑performance smart network gun‑type camera that uses Sony’s ExwavePRO™ progressive‑scan CCD and DEPA intelligent technology for clear images even in low‑light conditions. It delivers up to 30 fps at 768×576 resolution, supports MPEG‑4/JPEG dual streams, and includes features such as day/night conversion, gamma adjustment, voice alarm, date/time overlay, privacy masking and PoE power.
The manual provides technical specifications—including a 2.7× optical zoom varifocal lens, 0.2 lux minimum illumination for color, and a compact size of 82.5 × 63 × 172.7 mm—and details on installation accessories such as mounting cable, CD‑ROM with user guide, IP‑setting program and privacy‑masking tool. This manual is written in Chinese.
SONY SNC-CS20 specifications
| Maximum video resolution | 768×576 |
|---|---|
| Maximum frame rate | 30 fps |
| Optical zoom | 2.7× |
| Power supply | PoE (IEEE‑802.3af) / AC 24 V / DC 12 V |
| Dimensions (W×H×L) | 82.5 × 63 × 172.7 mm |
| Minimum illumination (color) | 0.2 lux (50 IRE, F1.0, AGC ON) |
All SONY SNC-CS20 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum video resolution of the SNC‑CS20?
The camera can output video at up to 768 × 576 pixels.
Does the SNC‑CS20 support Power over Ethernet?
Yes, it can be powered via PoE (IEEE‑802.3af) as well as AC 24 V or DC 12 V.
