Analog Devices AD708 Ultralow Offset Voltage Dual Op Amp Datasheet
The AD708 is a high precision, dual monolithic operational amplifier designed for applications requiring excellent DC precision. It features an ultra-low maximum offset voltage of 30 pV and low drift characteristics, making it ideal for constructing high-gain instrumentation amplifiers.
Available in four performance grades (AD708J, AD708A, AD708B, and AD708S), the device is offered in various packages including PDIP, CERDIP, and hermetic CERDIP/883B. The document provides comprehensive electrical specifications, absolute maximum ratings, typical performance characteristics graphs, and application circuit examples.
Analog Devices AD708 specifications
| Input Offset Voltage (Max) | 30 pV |
|---|---|
| Offset Voltage Drift (Max) | 0.3 pV/°C |
| Voltage Noise (0.1 Hz to 10 Hz) | 0.35 pV p-p |
| Open-Loop Gain (Min) | 5 million V/V |
| Common-Mode Rejection Ratio (Min) | 130 dB |
Source: Analog Devices AD708 Ultralow Offset Voltage Dual Op Amp Datasheet
All Analog Devices AD708 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
- Analog Devices AD708 Ultralow Offset Voltage Dual Op Amp Datasheet 16 p
- Analog Devices AD708 Ultralow Offset Voltage Dual Op Amp Datasheet 8 p
- Analog Devices AD708 Ultralow Offset Voltage Dual Op Amp Datasheet 8 p
- Analog Devices AD708 Dual Operational Amplifier Datasheet Rev C 16 p
- Analog Devices AD708 Dual Op Amp Datasheet 16 p
Questions answered in these manuals
What is the maximum offset voltage of the AD708?
The maximum offset voltage is 30 pV.
From: Analog Devices AD708 Ultralow Offset Voltage Dual Op Amp Datasheet
Which performance grade is rated for commercial temperature range?
The AD708J is rated over the commercial temperature range of 0°C to 70°C.
From: Analog Devices AD708 Ultralow Offset Voltage Dual Op Amp Datasheet
Is a single version of the AD708 available?
Yes, the single version is called the AD707.
From: Analog Devices AD708 Ultralow Offset Voltage Dual Op Amp Datasheet
What is the maximum offset voltage match for the AD708?
The maximum offset voltage match is 30 mV.
From: Analog Devices AD708 Ultralow Offset Voltage Dual Op Amp Datasheet
What is the maximum offset voltage drift for the AD708?
The maximum offset voltage drift is 0.3 µV/°C.
From: Analog Devices AD708 Ultralow Offset Voltage Dual Op Amp Datasheet
Is the AD708 available in military grade?
Yes, the AD708S is rated over the military temperature range of -55°C to +125°C.
From: Analog Devices AD708 Ultralow Offset Voltage Dual Op Amp Datasheet
