Phoenix Contact MCR-PLUGTRAB PT Surge Protection Module Application Note

The Phoenix Contact MCR-PLUGTRAB PT application note describes surge protection for DeviceNet power and CAN data lines, with specifications, installation…

Brand: Phoenix Contact
Document type: Application Note
Language: English
Pages: 61
File format: PDF
File size: 1.7 MB
Published: 28 September, 2026
Updated: 28 September, 2026
MD5 checksum: 175AAF7F0F8F1853A5C4FE9908473C6D
PDF: Phoenix Contact MCR-PLUGTRAB PT Surge Protection Module Application Note PDF

About this manual

The MCR-PLUGTRAB PT is a pluggable surge protection module that safeguards both the 24 VDC power supply and the CAN‑high/CAN‑low data signals in DeviceNet and other CAN‑based networks. It consists of a DIN‑rail‑mounted header and a replaceable plug, with color‑coded keys to prevent mismatched connections.

The document provides dimensions, a circuit diagram, technical data (voltage, current, surge ratings, response time, temperature range), detailed installation and removal instructions for the DIN‑rail header, and ordering data for the header, plug and accessories.

What's inside

Introduction
Dimensions
Circuit Diagram
Application Example
Technical Data
Installing and Removing the MCR-PLUGTRAB Module
Ordering Data

Specifications

Operating Temperature Range	-40 °C to +85 °C

Frequently asked questions

What network protocols can the MCR-PLUGTRAB PT protect?

It can protect any protocol that uses the CAN physical layer, such as DeviceNet, CANopen and NMEA 2000.

What is the recommended tightening torque for the terminal screws?

Tighten the terminal screws to 0.5 Nm.

Download PDF (1.7 MB)
