This document introduces the plug component product FRONT-MC 1,5/ 5-ST-3,81 from PHOENIX CONTACT GmbH & Co. KG, including its current, voltage, and connection type.
The FRONT-MC 1.5/5-ST-3.81 is a green‑colored plug component with a screw connection, rated for 8 A and 160 V. It features a 3.81 mm pitch and five positions, suitable for industrial electrical connections.
The sheet provides detailed technical parameters, dimensional drawings, connection data, certification information and a list of compatible accessories and related products. This manual is written in Chinese.
| Nominal current | 8 A |
|---|---|
| Nominal voltage | 160 V |
| Pitch | 3.81 mm |
| Number of positions | 5 |
| Insulating material group | I |
| Rated surge voltage (III/3) | 2.5 kV |
| Connection type | Screw connection |
| Color | green |
| Tightening torque (min) | 0.22 Nm |
| Tightening torque (max) | 0.25 Nm |
The nominal current is 8 A.
The pitch is 3.81 mm.
It has five positions.
