MC 1,5/ 8-STF-3,5 is a connector produced by PHOENIX CONTACT. The rated current is 8 A, the rated voltage is 160 V, the pitch is 3.5 mm, the number of positions is 8, the connection type is screw connection, and the color is green.
The MC 1,5/8-STF-3,5 is a green, 8‑position terminal block with a 3.5 mm pitch, rated for 8 A and 160 V. It features a screw connection, press‑in or soldering assembly options, and complies with WEEE/RoHS regulations.
The product is supplied in packs of 50 pieces (EAN 4017918113483) and weighs 0.00659 kg per piece. Technical data such as tightening torque (0.22 Nm min, 0.25 Nm max) and surge voltage ratings are provided, along with certification approvals (CSA, CUL, UL, VDE‑PZI).
| Nominal current | 8 A |
|---|---|
| Nominal voltage | 160 V |
| Pitch | 3.5 mm |
| Number of positions | 8 |
| Color | green |
| Weight per piece | 0.00659 kg |
| Pack quantity | 50 pcs |
| EAN | 4017918113483 |
| WEEE/RoHS compliance date | 01/01/2003 |
The terminal block is rated for a nominal current of 8 A.
It has 8 positions.
The pitch is 3.5 mm.
Yes, it has been RoHS compliant since 01/01/2003.
