FMCD 1,5/ 4-ST-3,5 is a connector produced by PHOENIX CONTACT with a rated current of 8 A, rated voltage of 160 V, pitch of 3.5 mm, spring-cage connection type and green color.
The FMCD 1.5/4-ST-3.5 is a 4‑position spring‑cage connector plug designed for nominal currents of 8 A and nominal voltages of 160 V. It features a 3.5 mm pitch and is supplied in green‑colored housing.
Key specifications include a length of 22.9 mm, height of 16 mm, and a weight of 0.004858 kg per piece. The component complies with RoHS/WEEE regulations since May 2007 and is listed under customs tariff 85366990.
| Nominal current | 8 A |
|---|---|
| Nominal voltage | 160 V |
| Pitch | 3.5 mm |
| Number of positions | 4 |
| Connection type | Spring‑cage |
| Length | 22.9 mm |
| Height | 16 mm |
| Dimension a | 10.5 mm |
| Weight per piece | 0.004858 kg |
| EAN | 4046356295123 |
| RoHS/WEEE compliance date | 05/22/2007 |
The connector is rated for a nominal current of 8 A.
It has four positions.
The pitch is 3.5 mm.
It has been RoHS/WEEE compliant since 05/22/2007.
