A selection guide for Glenair Series ITS and ITS‑RG MIL‑DTL‑5015 reverse bayonet connectors, covering styles, backshells, contacts and ordering information.
The Glenair Series ITS and ITS‑RG product selection guide provides detailed information on MIL‑DTL‑5015 reverse bayonet connectors designed for harsh rail, industrial and military environments. It includes connector styles, backshell options, contact arrangements, and part‑number data to help engineers choose the right configuration.
The guide also describes the OCTOBYTE™ contacts, which are vibration‑resistant, RoHS‑compliant and rated IP67 (IP68 on request). It highlights the reverse bayonet coupling mechanism, rated for 2,000 mating cycles, and lists compatible cable types such as CAT 5‑7A, MVB‑WTB and RG58 coaxial cable.
| Environmental rating | IP67 (IP68 on request) |
|---|---|
| Mating cycles | 2,000 matings |
| Compatible Ethernet cable types | CAT 5 to CAT 7A, MVB‑WTB, RG58 coax |
The connectors are RoHS‑compliant and rated IP67, with IP68 available on request.
The reverse bayonet coupling is rated for 2,000 mating cycles.
They can be used with Ethernet cables ranging from CAT 5 to CAT 7A, as well as MVB‑WTB and RG58 coaxial cables.
