FDS6294 is a N-channel fast switching power MOSFET designed by Fairchild Semiconductor Corporation. Its features include low gate charge, low RDS(ON) and fast switching speed. Applications include DC/DC converters, power management and load switches.
The Fairchild Semiconductor FDS6294 is a 30V N-Channel MOSFET optimized for low gate charge, low on-resistance, and fast switching speed. It is specifically designed to improve the efficiency of DC/DC converters using synchronous or conventional switching PWM controllers. Key applications include high-performance trench technology for low on-resistance, DC/DC converters, power management, and load switches. The device is RoHS compliant and features high power and current handling capabilities.
| Drain-Source Voltage | 30 V |
|---|---|
| Continuous Drain Current | 13 A |
| Gate Charge (Typical) | 10 nC |
| Operating Junction Temperature Range | -55 to +175 °C |
| Thermal Resistance Junction-to-Ambient | 50 °C/W |
The FDS6294 is designed for DC/DC converters, power management, and load switch applications.
Yes, the FDS6294 is RoHS compliant.
The maximum continuous drain current is 13 A.
