ADVANCED POWER TECHNOLOGY EUROPE APT10050B2LC APT10050LLC 1000V 21A 0.500W handbook

This document describes the maximum ratings, technical characteristics, and static electrical characteristics of the APT10050 model.

Brand: Advanced
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 2
File format: PDF
File size: 69 KB
Published: 12 July, 2012
Updated: 29 September, 2023
MD5 checksum: 7B667147087FDD723A2D16F10BBF145F
PDF: ADVANCED POWER TECHNOLOGY EUROPE APT10050B2LC APT10050LLC 1000V 21A 0.500W handbook PDF

About this manual

This document provides technical specifications for the Advanced APT10050B2LC, a low gate charge, high voltage N-Channel enhancement mode power MOSFET. The device features a T-MAX or TO-264 package and is designed for fast switching speeds with optimized gate layout.

What's inside

Maximum Ratings
Static Electrical Characteristics
Dynamic Characteristics
Source-Drain Diode Ratings
Thermal Characteristics
Package Outline

Frequently asked questions

What is the package type for the APT10050B2LC?

The device is available in T-MAX or TO-264 package.

Is the APT10050B2LC avalanche tested?

Yes, the device is 100% avalanche tested.
