FDMA2002NZ is a dual N-Channel PowerTrench MOSFET with an operating voltage of 30V and an operating current of 2.9A. It features low on-state resistance and is suitable for dual switching requirements in cellular handsets and other ultra-portable applications.
The FDMA2002NZ is a dual N-channel PowerTrench MOSFET designed specifically as a single package solution for dual switching requirements in cellular handsets and other ultra-portable applications. It features two independent N-channel MOSFETs with low on-state resistance to minimize conduction losses and is well-suited for linear mode applications.
| ESD Protection Level | 1.8kV |
|---|
The device supports a continuous drain current of 2.9 A when the junction temperature is 25°C and the gate-source voltage is 4.5 V.
The MOSFET is rated for operation and storage between -55°C and +150°C.
The device has a low profile with a maximum height of 0.8 mm.
