Fairchild FDMA7628 Single N-Channel MOSFET Datasheet

This is a document about FDMA7628 Single N-Channel 1.5V Specified PowerTrench® MOSFET. The product features a maximum rDS(on) of 14.5 mΩ, a maximum voltage of 20V, a maximum current of 9.4A, and a maximum power dissipation of 1.9W. It is designed with a low profile of 2x2mm and is RoHS compliant.

Brand: Fairchild
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 7
File format: PDF
File size: 242 KB
Published: 11 July, 2012
Updated: 28 September, 2023
MD5 checksum: 2CF0B882C69DC3C186A59695C08281C5
PDF: Fairchild FDMA7628 Single N-Channel MOSFET Datasheet PDF

About this manual

The document describes the Fairchild Semiconductor FDMA7628, a single N-Channel MOSFET designed using the advanced PowerTrench process. It is specified for operation at low voltages (1.5 V) and features a low profile MicroFET package measuring 2x2 mm.

What's inside

Features
General Description
Applications
Maximum Ratings
Electrical Characteristics
Thermal Characteristics
Typical Characteristics
Package Marking

Specifications

Package Type	MicroFET 2X2

Frequently asked questions

What are the applications for this MOSFET?

It is designed for use in Li-Ion Battery Packs and DC-DC Buck Converters.

Is the device RoHS compliant?

Yes, the document states that the product is RoHS Compliant.
