The LMH6551 is a high performance voltage feedback differential amplifier with high speed and low distortion characteristics, suitable for driving high performance ADCs and balanced transmission lines like CAT 5 data cables. It can handle a wide range of video and data formats. With external gain set resistors, it can be used at any desired gain. The high speed and flexibility make it suitable for use as an IF amplifier in high performance communications equipment. The LMH6551 is available in SOIC and MSOP packages, saving space.
The LMH6551 is a high performance voltage feedback differential amplifier designed for driving high performance ADCs and balanced transmission lines like CAT 5 data cables. It offers high speed and low distortion necessary for video and data formats, with external gain set resistors allowing use at any desired gain. The device is available in space-saving SOIC and MSOP packages.
| Small Signal -3 dB Bandwidth | 370 MHz |
|---|---|
| Large Signal -3 dB Bandwidth | 340 MHz |
| Slew Rate | 2400 V/s |
| Settling Time to 0.05% | 18 ns |
| HD2/HD3 Distortion @ 5 MHz | -94/-96 dB |
| Operating Temperature Range | -40°C to +125°C |
| Total Supply Voltage | 3V to 12V |
The LMH6551 is available in SOIC and MSOP packages.
The typical small signal -3 dB bandwidth is 370 MHz.
The typical slew rate is 2400 V/s.
