The LMH6582 is a high performance, non-blocking, analog crosspoint switch. The LMH6582 is designed for high speed, DC coupled, analog signals like high resolution video (UXGA and higher).
The LMH6582 is a high-speed, DC coupled, analog crosspoint switch designed for high-resolution video signals like UXGA and higher. It features 16 inputs and 8 outputs with a non-blocking architecture, allowing any output to be connected to any input. The device includes fully buffered inputs for impedance matching and buffered outputs capable of driving up to two back-terminated video loads (75Ω). It is controlled via a 4-pin serial interface supporting both single serial and addressed chain modes.
| Gain Options | Gain of 1 or 2 |
|---|---|
| Package | 64-pin exposed pad TQFP |
| Operating Temperature Range | -40°C to +85°C |
The device operates with a supply voltage between +3V and +5.5V.
The switch can source up to +70 mA of output current under these conditions.
