LMH6624/LMH6626 offer wide bandwidth (1.5GHz for single, 1.3GHz for dual) with very low input noise (0.92nV/ , 2.3pA/ ) and ultra low dc errors (100µV VOS, ±0.1µV/˚C drift) providing very precise operational amplifiers with wide dynamic range. This enables the user to achieve closed-loop gains of greater than 10, in both inverting and non-inverting configurations.
The LMH6624 and LMH6626 are ultra low noise wideband operational amplifiers designed for applications such as instrumentation, ultrasound, and professional audio systems. The LMH6624 is a single-channel device, while the LMH6626 is a dual-channel device. Both offer wide bandwidth with very low input noise and ultra low DC errors, enabling precise operation with closed-loop gains greater than 10.
| Gain Bandwidth (LMH6624) | 1.5GHz |
|---|---|
| Gain Bandwidth (LMH6626) | 1.3GHz |
| Input Voltage Noise (LMH6624) | 0.92nV/√Hz |
| Input Voltage Noise (LMH6626) | 1.0nV/√Hz |
| Input Offset Voltage (Typical) | ±0.95mV |
| Slew Rate (LMH6624, AV=20) | 350V/µs |
| Supply Voltage Range (Dual) | ±2.5V to ±6V |
| Supply Voltage Range (Single) | +5V to +12V |
| Output Swing (LMH6624, RL=100Ω, ±6V) | ±4.4V |
| Output Swing (LMH6626, RL=100Ω, ±6V) | ±4.3V |
| Package Types | SOT23-5, SOIC-8, MSOP-8 |
They are suitable for instrumentation sense amplifiers, ultrasound pre-amps, magnetic tape & disk pre-amps, wide band active filters, professional audio systems, opto-electronics, and medical diagnostic systems.
The average drift is ±0.25 µV/°C for the LMH6624 and ±0.2 µV/°C for the LMH6626.
The typical supply current per channel is 16mA at ±2.5V and 16mA at ±6V.
