The LMH6570 is a high performance analog multiplexer optimized for professional grade video and other high fidelity high bandwidth analog applications. It features 0.02% and 0.05˚ differential gain and phase errors for NTSC and PAL video signals while driving a single, back terminated 75Ω load. This multiplexer also supports 8ns channel switching time, 70dB channel to channel isolation and -68dB and -84dB HD2 and HD3.
The LMH6570 is a high-performance analog multiplexer optimized for professional-grade video and high-bandwidth analog applications. It features a 500 MHz bandwidth at 500 mV output and a 400 MHz bandwidth at 2 Vpp output, with a slew rate of 2200 V/us. The device supports composite video applications with low differential gain and phase errors for NTSC and PAL signals.
| Slew Rate | 2200 V/us |
|---|---|
| Channel Switching Time | 8 ns |
| Supply Voltage Range | 6V to 12V |
| Operating Temperature | -40 °C to 85 °C |
| Package Type | 8-Pin SOIC |
The bandwidth is 400 MHz at a 2 Vpp output signal level.
The channel switching time is 8 ns.
The maximum supply voltage is 13.2V.
