OM6213 is a 48×84 pixels matrix LCD driver with high performance and reliability. It is suitable for various applications including industrial instruments, automotive displays, and portable devices.
The Philips OM6213 is a low-power CMOS integrated circuit designed to drive graphic displays of 48 rows and 84 columns. It functions as a single-chip controller/driver, incorporating all necessary display functions including the generation of LCD supply and bias voltages. This design minimizes the need for external components and reduces power consumption, making it suitable for battery-operated systems.
| Display Resolution | 48 rows, 84 columns |
|---|---|
| Display Data RAM Size | 48 x 84 bits |
| Logic Supply Voltage | 2.5 to 3.3 V |
| Display Supply Voltage | 4.5 to 9.0 V |
| Operating Temperature | -40 to +85 °C |
| Serial Interface Speed | 4.0 Mbit/s |
No, the on-chip oscillator requires no external components, though an external clock is also possible.
The maximum serial interface speed is 4.0 Mbit/s.
