ZETEX COMPLEMENTARY 100V ENHANCEMENT MODE MOSFET H-BRIDGE ZXMHC3A07T8 handbook

This product is a 100V enhancement mode MOSFET with low on-resistance and fast switching speed, suitable for high efficiency, low voltage, power management applications

Brand: Zetex
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 10
File format: PDF
File size: 276 KB
Published: 02 July, 2012
Updated: 30 September, 2023
MD5 checksum: 616BCAF69406E34298E124BDE9A22AF1
PDF: ZETEX COMPLEMENTARY 100V ENHANCEMENT MODE MOSFET H-BRIDGE ZXMHC3A07T8 handbook PDF

About this manual

The ZXMHC10A07T8 is a complementary 100V enhancement mode MOSFET H-bridge from Zetex. This device utilizes a unique trench MOSFET structure to combine low on-resistance with fast switching speed, making it ideal for high efficiency, low voltage power management applications such as single phase DC fan motor drives. The package is a single SM-8 surface mount type.

What's inside

Summary
Features
Applications
Ordering Information
Absolute Maximum Ratings
Thermal Resistance
Electrical Characteristics
Typical Characteristics
Package Outline
Package Dimensions

Specifications

Power Dissipation	13 W
Operating Temperature Range	-55 to +150 °C
Junction to Ambient Thermal Resistance	94.5 °C/W
Static Drain-Source On-State Resistance	0.7 Ohm
Package Type	SM-8 Surface Mount

Frequently asked questions

What are the main applications for this MOSFET?

It is ideal for high efficiency, low voltage, power management applications, specifically single phase DC fan motor drives.

What is the maximum operating temperature?

The operating and storage temperature range is from -55 to +150 °C.
