The ZXMC3AM832 is a 30V N-channel enhancement mode MOSFET from Zilog. It features low on-resistance and fast switching speed, making it ideal for high efficiency, low voltage power management applications.
The ZXMC3AM832 is a dual 30V N-channel and P-channel enhancement mode MOSFET packaged in a 3mm x 2mm MLP (Micro Leaded Package). It combines low on-resistance with fast switching speed, making it ideal for high efficiency, low voltage power management applications such as MOSFET gate drives, LCD backlight inverters, and motor control. Key benefits include improved circuit efficiency, reduced PCB area, and reduced component count.
| Drain-Source Voltage (N-Channel) | 30 V |
|---|---|
| Drain-Source Voltage (P-Channel) | -30V |
| On-Resistance (Typical N-Channel) | 0.12 Ohm |
| On-Resistance (Typical P-Channel) | 0.21 Ohm |
| Package Type | 3mm x 2mm MLP |
| Junction to Ambient Thermal Resistance (Still Air, 8 sq cm) | 83.3 °C/W |
The device is ideal for MOSFET gate drives, LCD backlight inverters, and motor control applications.
The device is packaged in a 3mm x 2mm MLP (Micro Leaded Package) outline.
The typical on-resistance for the N-channel device is 0.12 Ohms.
