The GT3 series is a connector launched by TE. It has low-profile and standard types.
This leaflet describes the GT3 series of connectors, including the low‑profile GT3, the standard GT3B, and the right‑angle GT3TK and GT3TKW families. It provides details on mounting options, pin configurations, material finishes and color coding for each variant.
Each connector type is presented with its part number, recommended board mounting pattern, and packaging information, helping designers select the appropriate component for their printed‑circuit‑board designs.
| Mounting screw hole diameter | 2.6 mm |
|---|---|
| Tab width | size 040 |
| GT3‑16DP‑2.5DSA pin header | 7‑pin, PBT, Black |
| GT3B‑16DP‑2.5DSA terminal | 19‑pin, Brass, Tin plating |
| GT3TK‑8DP‑DSA housing color | Brown |
| GT3TKW‑12DP‑DSA housing color | Natural |
| Recommended mounting screw | M3, nominal diameter 3L‑8 |
The mounting screw hole diameter is 2.6 mm.
Terminals are made of brass with a tin plating finish.
The GT3TKW housing is natural colored.
It uses a 7‑pin PBT header in black.
