EMZ8/UMZ8N is a dual transistor combination introduced by ROHM, consisting of 2SA2018 and 2SC2412K, both of which are packaged in EMT or UMT packages.
The datasheet presents the EMZ8 and UMZ8N dual transistors, each containing a 2SA2018 and 2SC2412K chip, packaged in EMT or UMT. It lists dimensions, absolute maximum ratings, electrical characteristics, and typical performance curves.
The document also includes packaging markings, application notes, and legal notices from ROHM, with contact information for further technical support.
| Package type | EMT or UMT |
|---|---|
| Maximum power dissipation per element | 120 mW |
| Transition frequency (typ) Tr1 | 260 MHz |
| Transition frequency (typ) Tr2 | 180 MHz |
| Storage temperature range | -55°C to +150°C |
The datasheet states that 120 mW per element must not be exceeded.
They are offered in EMT or UMT packages.
