The document describes the features and characteristics of the PC terminal block PTSA 0,5/ 6-2,5-Z from PHOENIX CONTACT GmbH & Co. KG. It has 10 positions, a nominal current of 2A, a nominal voltage of 160V, a pitch of 2.5mm, a spring-cage connection type, a conductor/PCB connection direction of 45°, a green color, and offset soldering legs with a two-row structure.
The PTSA 0.5/6-2.5-Z is a spring‑cage terminal block with a 2.5 mm pitch, green housing, and six positions. It is rated for a nominal current of 2 A and a nominal voltage of 160 V, with a 45° conductor‑to‑PCB connection direction.
The handbook provides detailed technical data, including dimensions, surge voltage ratings, derating curves, and certification information. It also contains drawing references, pin spacing details, and packaging specifications such as weight and EAN code.
| Nominal current | 2 A |
|---|---|
| Nominal voltage | 160 V |
| Pitch | 2.5 mm |
| Number of positions | 6 |
| Type of connection | Spring‑cage |
| Conductor/PCB connection direction | 45° |
| Color | green |
The terminal block is rated for a nominal current of 2 A.
The pitch is 2.5 mm.
It has six positions.
