This is a product description from phoenixcontact, introducing the characteristics and features of FRONT-MC 1,5/10-ST-3,81 product, including rated current, rated voltage, pitch, number of positions, connection type, color and other information.
This handbook describes the FRONT-MC 1,5/10-ST-3,81 terminal block, a 10‑position plug component with a 3.81 mm pitch and green color. It lists the nominal current (8 A), nominal voltage (160 V), connection type (screw connection), and mechanical dimensions.
Additional sections cover tightening torque requirements, insulating material details, certification approvals (CB, CSA, CUL, UL, VDE‑PZI), and a list of compatible accessories and related product variants.
| Nominal current | 8 A |
|---|---|
| Nominal voltage | 160 V |
| Pitch | 3.81 mm |
| Number of positions | 10 |
| Connection type | Screw connection |
| Color | green |
| Insulating material group | I |
| Rated surge voltage | 2.5 kV |
| Tightening torque (min) | 0.22 Nm |
| Tightening torque (max) | 0.25 Nm |
| Dimension a | 34.29 mm |
The nominal current is 8 A.
The pitch is 3.81 mm.
It is certified by CB, CSA, CUL, UL, and VDE‑PZI.
