PTSA 0,5/ 4-2,5-Z is a PC terminal block with a nominal current of 2A, rated voltage of 160V, pitch of 2.5mm, number of positions of 4, type of connection of spring-cage conn., conductor/PCB connection direction of 45 °, color of green, offset soldering legs, two-rowed.
The PTSA 0,5/4-2,5-Z is a 4‑position, spring‑cage terminal block from Phoenix Contact, designed for low‑current applications with a 2 A nominal current and 160 V nominal voltage.
The handbook includes technical data such as pitch, dimensions, rated surge voltages, connection details, certification information, wiring diagrams and a derating chart for the 5‑position version.
| Nominal current | 2 A |
|---|---|
| Nominal voltage | 160 V |
| Pitch | 2.5 mm |
| Number of positions | 4 |
| Type of connection | Spring‑cage |
| Conductor/PCB connection direction | 45° |
| Color | green |
| Weight per piece | 0.001693 kg |
It is rated for 2 A nominal current.
The pitch is 2.5 mm.
It has 4 positions.
The nominal voltage is 160 V.
