This document is a detailed information of the PC 5/ 2-STCL-7,62 product from phoenix contact. It includes the product's name, model, image, specifications, parameters, etc.
The PC 5/2-STCL-7,62 is a 5‑position, screw‑connection plug component offered by Phoenix Contact. It is rated for 41 A nominal current and 1000 V nominal voltage, with a 7.62 mm pitch and green housing.
The document provides detailed technical data such as tightening torque values, conductor cross‑section ranges, derating curves for different ambient temperatures, and certification information (UL, CUL). Commercial details like EAN, packaging quantity and weight are also listed.
| Nominal current | 41 A |
|---|---|
| Nominal voltage | 1000 V |
| Pitch | 7.62 mm |
| Number of positions | 2 |
| Connection type | Screw connection |
| Color | green |
| Weight per piece | 0.011239 kg |
| EAN | 4046356175388 |
The connector is rated for a nominal current of 41 A.
It is rated for a nominal voltage of 1000 V.
The recommended tightening torque is 0.7 Nm minimum and 0.8 Nm maximum.
The pitch of the connector is 7.62 mm.
