MSTBT 2,5/ 6-ST-5,08 is a connector manufactured by PHOENIX CONTACT. It has a rated current of 12 A, a rated voltage of 250 V, a screw connection interface and a green color.
The MSTBT 2,5/6-ST-5,08 is a DIN‑rail mounted terminal block with a 5.08 mm pitch, six positions, and a nominal current of 12 A at 250 V. Technical data include tightening torque (0.5 Nm min, 0.6 Nm max), rated surge voltage of 4 kV, and a weight of 0.01047 kg per piece.
The handbook lists compatible accessories such as insertion bridges, cable housings, marker cards, and tools, and provides certification information (CB, CSA, CUL, UL, VDE‑PZI). Ordering details and the manufacturer’s contact address are also included.
| Nominal current | 12 A |
|---|---|
| Nominal voltage | 250 V |
| Pitch | 5.08 mm |
| Number of positions | 6 |
| Connection type | Screw connection |
| Weight per piece | 0.01047 kg |
The nominal current is 12 A.
It has six positions.
The pitch is 5.08 mm.
The minimum torque is 0.5 Nm and the maximum is 0.6 Nm.
